Wika 73x.25 Series 4.5" or 6" Aluminum Differential Pressure Gauge, Membrane Sensing Element, SS or Inconel Wetted Parts
The Wika 73x.25 Series Differential Pressure Gauge is engineered for accuracy and durability in demanding industrial applications. This gauge excels at measuring pressure differences in systems with high static process pressures, making it ideal for various industrial settings. An added benefit is its exceptional resistance to corrosion, allowing it to handle harsh environments with either liquid or gaseous media.
The 73x.25 Series incorporates a membrane sensing element, known for its responsiveness and ability to withstand pressure spikes and vibrations. The gauge is housed in a protective black powder-coated aluminum case, ensuring its longevity even in challenging conditions. For added convenience, the 73x.25 Series features an external zero point adjustment, allowing for easy on-site calibration.
With a maximum working pressure of 3000 psid, the 73x.25 Series is built to tackle demanding applications. The gauge boasts a wide range of differential pressure measurement capabilities, reaching up to 600 psid. This versatility makes it suitable for various industrial processes, excelling in applications involving corrosive media or high-pressure environments.
When you need a reliable differential pressure gauge for harsh conditions, the Wika 73x.25 Series is the perfect solution. For top-tier industrial gauges and exceptional customer service, look no further than Branom, your trusted supplier for all your measurement needs.
Specifications
| Wika 73x.25 | |
|---|---|
| Case Filling | [732.25] Without, [733.25] With |
| Nominal Size | [9] 4.5", [F] 6" |
| Scale Range | ￭ psid ￭, [PG310] 15 psid, [PG321] 30 psid, [PG341] 60 psid, [PG369] 100 psid, [PG421] 300 psid, [PG428] 400 psid, [PG435] 500 psid, [PG441] 600 psid, ￭ inH2Od ￭, [IG225] 100 inH2Od, [IG235] 150 inH2Od, [IG250] 200 inH2Od, [IG275] 300 inH2Od, [IG310] 400 inH2Od |
| 2nd Scale | [Z] Without, [L] kPa |
| Process Connection | [AH] 2 x 1/4 NPT Female, [AA] 2 x G 1/4 Female, [AK] 2 x 1/2 NPT Female, [AD] 2 x G 1/2 Female |
| Connector Location | [A] Back Mount, [J] Top / Bottom Connections |
| Additional Mounting Device | [Z] Without, [B] Mounting Kit For Surface Or Pipe Mounting, Stainless Steel |
| Window | [EQ] Polycarbonate, [HQ] Laminated Safety Glass (4.5"), [HQ] Laminated Safety Glass (6") |
| Case Material | [C] Black Powder-Coated Aluminum, [A] Stainless Steel (4.5"), [A] Stainless Steel (6") |
| Case Filling Fluid | [ZAD1A] Without, [AAD1A] Glycerine, [9AD1A] Silicone Oil, 350 cSt, [PAD1A] Silicone, 1000 cSt |
| Color for Inner Scale | [ZP1AZZZZZZZGOZZ2] Without, [CP1AZZZZZZZGOZZ2] Red, [AP1AZZZZZZZGOZZ2] Black |
| Pointer | [Q] Aluminum, Black, w/Metal Hub |
| Special Design Features | [N-ZZ] Nace Sour Gas Service |
| Certificates | [Z] Without |
| Additional Ordering Info | [Z] Without |
| Dial | [AD] Aluminum, White, w/Stop-Pin |
| Dial Background | [1] White |
| Color for Outer Scale | [A] Black |
| Text / Mark on Dial | [P] *Δp* *Differential Pressure* |
| Serial Number on Dial | [1] Serial Number *...* |
| Manufacturer Logo | [A2] *Wika®* |
| Logo Options | [ZZZZZZZ] Without |
| Accuracy Class on Dial | [G] *± 1.0%* |
| Norm-Mark on Dial | [O] *Max. Stat. and Overpressure Safe: 3000 psi* *Proof Pressure: 4500 psi* |
| Additional Mark | [Z] Without |
| Text / Mark on Dial | [Z] Without |
| Stop Pin on Dial | [2] at 6 o'clock |
| Gauge Features | |
|---|---|
| Gauge: Brand | Wika |
| Gauge: Type | Dial Indicating Gauge |
| Gauge: Model | 732.25, 733.25 |
| Gauge: Dial Size | 4-1/2 in (110 & 115 mm), 6 in (160 mm) |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Pressure Type | Differential Pressure |
| Gauge: Measuring Principle | Diaphragm Element |
| Gauge: Fill Type | Dry, Liquid Filled / Fillable |
| Gauge: Product Unit of Measure | psi, inH2Od |
| Gauge: Process Connection Size | 1/4 NPT Female, 1/2 NPT Female, G 1/4 Female, G 1/2 Female |
| Gauge: Process Connection Location | Back Mount, Top / Bottom Connections |
| Gauge: Process Connection Type | 2-Way (2 x) |
| Gauge: Wetted Material | Stainless Steel, Nickel Alloy |
| Gauge: Accuracy | ±1% |
| Gauge: Case Material | Aluminum |
| Gauge: Window | Polycarbonate, Laminated Safety Glass |
| Gauge: Dial Material | Aluminum |
| Gauge: Pointer Material | Plastic |
