Wika 232.54 Series 2.5" SS Pressure Gauge, Dry/Fillable, SS Wetted Parts, Removable Ring
The Wika 232.54 Series Stainless Steel Pressure Gauge is designed for adverse service conditions where pulsating or vibration is present. Ideal for the process industry, it serves sectors such as chemical and petrochemical, power stations, mining, onshore and offshore operations, environmental technology, mechanical engineering, and plant construction. This gauge is suitable for both gaseous and liquid media that will not obstruct the pressure system, ensuring reliable performance across various applications.
Featuring an all stainless steel construction, the Series 232.54 offers exceptional durability and resistance to corrosion, making it perfect for the most challenging environments. The gauge is capable of handling pressure ranges up to 15,000 psi (1,000 bar), providing accurate readings for high-pressure applications. Additionally, the new FlexWindow option available on 2-1/2” gauges enhances readability and durability, ensuring long-lasting performance.
When it comes to purchasing the Wika 232.54 Series Stainless Steel Pressure Gauge, Branom is the best store to choose from. Branom is renowned for its exceptional customer care, offering expert advice and support to help you find the perfect gauge for your needs. Trust Branom for quality products and outstanding service. Experience the Branom difference and equip your operations with the finest pressure gauge technology available.
Order Code Starts with: 232.54.063-
Specifications
| Wika 232.54 | |
|---|---|
| Scale Range | ￭ psi ￭, [PG310] 0/15 psi, [PG321] 0/30 psi, [PG341] 0/60 psi, [PG369] 0/100 psi, [PG411] 0/160 psi, [PG414] 0/200 psi, [PG421] 0/300 psi, [PG428] 0/400 psi, [PG441] 0/600 psi, [PG455] 0/800 psi, [PG469] 0/1000 psi, [PG510] 0/1500 psi, [PG514] 0/2000 psi, [PG521] 0/3000 psi, [PG528] 0/4000 psi, [PG534] 0/5000 psi, [PG541] 0/6000 psi, [PG552] 0/7500 psi, [PG569] 0/10000 psi, [PG610] 0/15000 psi, ￭ inHg / psi ￭, [PV310] -30 inHg/0 psi, [PV321] -30 inHg/15 psi, [PV331] -30 inHg/30 psi, [PV352] -30 inHg/60 psi, [PV379] -30 inHg/100 psi, [PV412] -30 inHg/160 psi, [PV415] -30 inHg/200 psi, [PV422] -30 inHg/300 psi, ￭ bar ￭, [BG310] 0/1 bar, [BG316] 0/1.6 bar, [BG320] 0/2 bar, [BG325] 0/2.5 bar, [BG340] 0/4 bar, [BG360] 0/6 bar, [BG410] 0/10 bar, [BG416] 0/16 bar, [BG440] 0/40 bar, [BG460] 0/60 bar, [BG510] 0/100 bar, [BG514] 0/140 bar, [BG516] 0/160 bar, [BG520] 0/200 bar, [BG525] 0/250 bar, [BG540] 0/400 bar, [BG560] 0/600 bar, [BG610] 0/1000 bar, ￭ bar vacuum ￭, [BV310] -1/0 bar, [BV316] -1/0.6 bar, [BV320] -1/1 bar, [BV325] -1/1.5 bar, [BV330] -1/2 bar, [BV340] -1/3 bar, [BV360] -1/5 bar, [BV410] -1/9 bar, [BV416] -1/15 bar, [BV425] -1/24 bar |
| 2nd Scale | [Z] Without, [B] bar, [P] psi, [L] kPa, [K] kg/cm2 |
| Process Connection | [NB] 1/4 NPT, [NH] 1/8 NPT |
| Connector Location | [U] Lower Mount, [B] Center Back Mount |
| Mounting Flange / Bracket | [Z] Without, [F] Front Flange, Polished SS, [G] Panel Mount w/Zinc Plated Mounting Brackets, [K] Panel Mount w/SS U-Clamp |
| Restrictor | [ZZ-ZZZ22I] Without, [QZ-ZZZ22I] SS, D 0.6 |
| Window | [HZI0Z] Laminated Safety Glass, [AZI0Z] Acrylic (PMMA) |
| Thread Protection | [Z2Z] Without, [12Z] With Thread Protection |
| Nominal Size | 2.5" |
| Special Design Features | [Z] Without |
| Certificates | [Z] Without |
| Approvals | [Z] Without |
| Additional Ordering Info | [Z22] Without |
| Accuracy Class | [I] +/- 2/1/2% (ASME B40.100 Grade A) |
| Overpressure Safety | [136] Full Scale Value |
| Case Material | [3] 304 SS |
| Case Surface | [6] Bare Case / Polished Ring |
| Pressure Element Material | [41AZ] 316 SS |
| Case Filling | [1] Prepared for Filling |
| Pointer | [A] Adjustable |
| Set / Drag Pointer | [Z] Without |
| Special Measuring Element | [Z] Without |
| Ingress Protection | [I] IP 65 |
| Movement | [0] SS |
| Assembly Accessory | [Z] Without |
| Packing | [2] Single Packing |
| Origin of Wetted Parts | [Z] Without Specification |
| Gauge Features | |
|---|---|
| Gauge: Brand | Wika |
| Gauge: Type | Dial Indicating Gauge |
| Gauge: Model | 232.54 |
| Gauge: Dial Size | 2-1/2 in (63 mm & 68 mm) |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Fill Type | Dry, Liquid Filled / Fillable |
| Gauge: Product Unit of Measure | psi / inHg, bar |
| Gauge: Process Connection Size | 1/8 NPT, 1/4 NPT |
| Gauge: Process Connection Location | Lower Mount, Center Back Mount |
| Gauge: Wetted Material | Stainless Steel |
| Gauge: Accuracy | ±2% |
| Gauge: Case Material | Stainless Steel |
| Gauge: Window | Acrylic (PMMA), Laminated Safety Glass |
| Gauge: Dial Material | Aluminum |
| Gauge: Pointer Material | Aluminum |
| Gauge: Bezel Material | Stainless Steel |
| Gauge: Window Ring | Bayonet Ring, Removable |
| Gauge: Pointer Type | Adjustable |
