Representative photo. Please check item description for details.
Wika 232.53 Series Stainless Steel Dry Pressure Gauge, 2.5" Dial, 0-5000 PSI, 1/4" NPT SS Lower Mount
This high-quality Bourdon tube pressure gauge has been designed especially for the process industry.
The use of high-quality stainless steel materials and the robust design are geared to applications in the chemical and process engineering industries. Thus the instrument is suitable for liquid and gaseous media, also in aggressive environments.
Applications
- For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive environments
- Chemical and petrochemical industries, oil and gas industry, power engineering and also water and wastewater technology
- Machine building and general plant construction
Details
Type 23X.5X, size 2.5" Stainless Steel, crimpedor removable bezel (53 or 54)
Model: 232.53.063
Specifications according to data sheet: 23X.53 and 23X.54
Nominal size: 2.5"
Measuring System: Stainless Steel
Case: Non-removable crimp ring
Scale range: 0/5000 psi
Process Connection: 1/4 NPT
Connector location: lower mount
Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
Material pressure element: Measuring System 316 SS
Case filling fluid: prepared for filling
Window: Polycarbonate
Dial description:
Pressure Gauge Standard: US-Standard
color for 1.scale (outside): black
dial background: White
*WIKA®*
serial number on dial: Serial number *...*
stop pin on dial: at zero
