Representative photo. Please check item description for details.
212.53 Series Ready to Fill Pressure Gauge, 2" Dial, 0 to 15 psi (bar), 1/4 NPT Brass Back Mount, U-Clamp Bracket
Manufacturer: Wika Instrument Lp
Mfg Product Code: 52858100
Weight: 0.01 lb(s)
On Hand: 0
Wika 4315014+PM0 Industrial Grade pressure gauges feature heavy-duty sensing elements and a stainless steel case for protection in harsh environments. Industrial gauges offer greater accuracy than commercial gauges and are typically used in more demanding applications. The pressure connection and wetted parts are made of copper alloy (brass). Recommended panel hole cutout dimension is 2.0" diameter.
Features
- Bourdon tube pressure gauges ,Stainless Steel case
- case:stainless steel model 213.53.050/063
- Model: 212.53
- Specifications according to data sheet: APM 21X.53 (APM 02.12)
- Measuring System: Copper Alloy
- Case: 304 Stainless Steel
- Case: Non-removable crimp ring
- Nominal size: 2"
- Scale range: 0/15 psi
- 2nd Scale / Special Scale: 2nd scale bar
- Process Connection: 1/4 NPT
- Connector location: back mount
- Mounting Flange/Bracket: U-clamp bracket, zinc-plated steel
- Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
- Case filling fluid: prepared for filling
- Pointer: Aluminium, Black
- Window: Plastic, clear
- Packing: single packing
- Dial description:
- Pressure Gauge Standard: US-Standard
- color for 1.scale (outside): black
- color for 2.scale (inside): red
- dial background: White
- Manufacturer logo: *WIKA®*
- stop pin on dial: at zero
Specifications
Gauge: Brand | Wika |
Gauge: Model | 212.53 |
Gauge: Dial Size | 2 in (50 mm) |
Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
Gauge: Pressure Type | Gauge Pressure |
Gauge: Measuring Principle | Bourdon Tube |
Gauge: Fill Type | Liquid Filled / Fillable |
Gauge: Product Unit of Measure | psi |
Gauge: 2nd Scale | bar |
Gauge: Process Connection Size | 1/4 NPT |
Gauge: Process Connection Location | Back Mount, Panel Mount |
Gauge: Process Connection Type | U-Clamp Panel Mount |
Gauge: Wetted Material | Copper Alloy (Brass) |
Gauge: Accuracy | ±2% |
Gauge: Case Material | Stainless Steel |
