Representative photo. Please check item description for details.

212.53 Series Ready to Fill Pressure Gauge, 2" Dial, 0 to 300 psi (bar), 1/4 NPT Brass Back Mount, U-Clamp Bracket

https://www.branom.com/web/image/product.template/542769/image_1920?unique=2636124
(0 review)

Manufacturer: Wika Instrument Lp

Mfg Product Code: 50987411

Weight: 0.01 lb(s)

On Hand: 0

Wika 50987411 Industrial Grade pressure gauges feature heavy-duty sensing elements and a stainless steel case for protection in harsh environments. Industrial gauges offer greater accuracy than commercial gauges and are typically used in more demanding applications. The pressure connection and wetted parts are made of copper alloy (brass). Recommended panel hole cutout dimension is 2.0" diameter.

Features

  • Bourdon tube pressure gauges ,Stainless Steel case
  • Case: Stainless steel model 213.53.050/063
  • Model: 212.53
  • Specifications according to data sheet: APM 21X.53 (APM 02.12)
  • Measuring System: Copper Alloy
  • Case: 304 Stainless Steel
  • Case: Non-removable crimp ring
  • Nominal size: 2"
  • Scale range: 0/300 psi
  • 2nd Scale / Special Scale: 2nd scale bar
  • Process Connection: 1/4 NPT
  • Connector location: back mount
  • Mounting Flange/Bracket: U-clamp bracket, zinc-plated steel
  • Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
  • Case filling fluid: prepared for filling
  • Pointer: Aluminium, Black
  • Window: Plastic, clear
  • Packing: Single packing
  • Dial description: Pressure Gauge Standard: US-Standard
  • Color for 1.scale (outside): black
  • Color for 2.scale (inside): red
  • Dial background: White
  • Stop pin on dial: at zero

44.60 44.6 USD 47.20

47.20

Not Available For Sale

  • Gauge: Brand
  • Gauge: Model
  • Gauge: Dial Size
  • Gauge: Scale Range
  • Gauge: Pressure Type
  • Gauge: Measuring Principle
  • Gauge: Fill Type
  • Gauge: Product Unit of Measure
  • Gauge: 2nd Scale
  • Gauge: Process Connection Size
  • Gauge: Process Connection Location
  • Gauge: Process Connection Location
  • Gauge: Process Connection Type
  • Gauge: Wetted Material
  • Gauge: Accuracy
  • Gauge: Case Material

This combination does not exist.


Product Datasheets

Datasheet 1

Specifications

Gauge: Brand Wika
Gauge: Model 212.53
Gauge: Dial Size 2 in (50 mm)
Gauge: Scale Range ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar)
Gauge: Pressure Type Gauge Pressure
Gauge: Measuring Principle Bourdon Tube
Gauge: Fill Type Liquid Filled / Fillable
Gauge: Product Unit of Measure psi
Gauge: 2nd Scale bar
Gauge: Process Connection Size 1/4 NPT
Gauge: Process Connection Location Back Mount, Panel Mount
Gauge: Process Connection Type U-Clamp Panel Mount
Gauge: Wetted Material Copper Alloy (Brass)
Gauge: Accuracy ±2%
Gauge: Case Material Stainless Steel
